Product Details:
Place of Origin: China
Brand Name: Philis
Certification: ISO
Model Number: glassfiber filter cloth
Payment & Shipping Terms:
Minimum Order Quantity: 100m
Price: Negotiable
Packaging Details: standard export package
Delivery Time: within 10 days
Payment Terms: T/T
Supply Ability: 10000m per week
Contact Now
Detailed Product Description
Material:: Fiberglass Model Number:: Glass Fiber Fabric
Usage:: Powder Filter Working Temperature:: 130 - 260 Degree
Efficiency:: 99.9% Technics:: Nowoven Needle Punched
High Light:

micron filter cloth

,

filter fabric roll

Compound Glass Fiber Filter Cloth Filter Bag for Air / Gas Filtration



Quick Detail:





High filtration efficiency ,long service life

Good anti - abrasion

High temperature grade

Anti - acid ,anti - alkali, chemical resistance

High porosity ,good air permeability

Good price quality

Laminated compound,grads counterchange





Description:



Glass fiber filter media, including fiberglass needle felt and woven fiberglass filter cloth,because of it's high temperature resistant, anti-condensation,dimensions stability, dust stripping is good, and high filtration efficiency is widely used in metallurgy, cement, power generation, carbon black, coal-fired boilers, chemical industry and waste incineration industries.





Specifications:



Glass fiber filter felt Technical parameters





The technical data of E-glass fiber bulked yarn fabric with PTFE membrane
Article Name E-glass fiber bulked yarn fabric with PTFE membrane
Ingredients Fiber Glass fiber yarn
Scrim Glass fiber bulked yarn
Weight g/m2 750
Thickness mm 0.8
Permeability L/dm2.min 20-40
Tensile breaking strength(N/5cm) Warp 2300
Weft 1900
Textured type Satin weave
Maximum shrink of 30 mins Temperature(°C) 260
% <1
Service Temperature(°C) Continuous 260
Instant 280
Finishing PTFE membrane
Application Cement, kiln head, kiln tail





































Glass Fiber Finished filter cloth specification:




Item No.
LOI (%) Weave Weight (g/m2) Mullen burst (kpa) Tensile strength (N/2.5cm) Air permeability(cm3/cm2/s·127pa) Finished Running temperature
(°C)
warp weft
FA301 > 10 double twill 780-850 > 6200 > 2400 > 2000 15-30 PTFE <260
FI301 > 10 double twill 780-850 > 6200 > 2400 > 2000 15-30 PI <260
FB302 > 2 1/3 twill 450-500 > 4500 > 2000 > 1200 20-36 PGS <260
FC302 > 5 1/3 twill 340-380 > 4500 > 2000 > 1200 20-36 AR <260
FA303 >10 1/3 twill 320-360 > 3500 > 1400 > 800 22-35 PTFE <260
FC303 > 5 1/3 twill 900-950 > 3400 > 1200 > 700 22-35 AR <260
FD502 > 7 satin 900-950 > 8000 > 3000 > 2400 15-25 PD <400
FA404 > 10 double twill 800-850 > 5000 > 2600 > 2200 15-30 PTFE <260
FE201 >1.7 satin 550-600 > 5500 > 2200 > 2000 20-35 PG <260
FE203 > 1.7 1/3 twill 550-600 > 5500 > 2200 > 2000 20-35 PG

<260






Notices:



glass fiber needle felt is one kind of high temperature resistant filter material with reasonable structure and excellent performance,it could be high temperature resistant,anti-abrasion,stable size,little elongation shrinkage ratio,high intension,also ultimate fiber of felt layer fiber,three dimensional micro pore structure,high porosity,small filter resistance to gas,it has higher speed and efficiency,Comparing with other high temperature resistant chemical fiber felt,it has the advantage of lower price,high temperature resistant,but due to high resistance, filtering efficiency is lower





Applications:



Chemical plant Cement plant

Steel iron plant Melting plant

Carbon black plant Electricity Industry



Compound Glass Fiber Cloth Industrial Filter Bag for Air / Gas Filtration 0Compound Glass Fiber Cloth Industrial Filter Bag for Air / Gas Filtration 1Compound Glass Fiber Cloth Industrial Filter Bag for Air / Gas Filtration 2

Compound Glass Fiber Cloth Industrial Filter Bag for Air / Gas Filtration 3Compound Glass Fiber Cloth Industrial Filter Bag for Air / Gas Filtration 4



Sample Service

A4 size Samples are free



Sample Delievary Flow:

Sample Inquiry→Sample Specification Confirmation→Stock Check→Courier Service Suppliers and Contact Conmfirmation→Delievary→Delievary Comfirmation
