Polyester Nylon PPS Filter Fabric

Polyester Nylon PPS Filter Fabric
Polyester Nylon PPS Filter Fabric Polyester Nylon PPS Filter Fabric Polyester Nylon PPS Filter Fabric

Large Image :  Polyester Nylon PPS Filter Fabric

Product Details:

Place of Origin: China
Brand Name: Philis
Certification: ISO
Model Number: PPS filter fabric

Payment & Shipping Terms:

Minimum Order Quantity: 200 meters
Price: Negotiable
Packaging Details: standard export package
Delivery Time: within 10 days
Payment Terms: T/T
Supply Ability: 10000m per week
Detailed Product Description
Filtration Grade:: Hepa Filter Usage:: Powder Filter
Brand Name:: Philis Filter Size:: Custiomized
Material:: PPS Technics:: Nowoven Needle Punched
High Light:

Non woven filter cloth

,

micron filter media

low oxidation gas filtration PPS filter fabric for coal fired boiler



Quick Detail:





High filtration efficiency, long service life

1.5mm to 3mm thickness

Weight from 350 to 800s

Width 2.1 meter maximum

High porosity ,good air permeability

Good price quality

Laminated compound,grads counterchange





Description:



PPS Short fibers can keep intensity completely and bear chemistry naturing inherently, keep good filtration performance among the abominable environment, reach ideal service life. In coal boiler, rubbish incinerator, power plant of fly ash filtering of pulse clear dust catcher, PPS filter felts are an ideal filtration material.





Specifications:







Compositions

PPS(Polyphenylene sulfide) fiber

 Weight(g/m2)

500~550

Thickness(mm)

1.8~2.1

Air permeability(m3/ m2/min)

12~10

Tension at break

(N/5×20cm)

Warp

>1100

Weft

>1200

Tensile Elongation

( % )

Warp

<35

Weft

<55

Prohibited to use temperature

Below the dew point

Working Temperature

(℃)

Continuous

170~190

Instantaneous

<220

Anti-acid

Super

Anti-alkali

Super

Anti-abrasion

Good

Post—treatment

Size-fixing at high temperature, thread burning, dipping, coating etc



Compositions PPS stable fiber PPS stable fiber
Weight (g/m2) 500 550
Thickness (mm) 1.8
Air permeability(m3/m2/min) 15 12

Tensile strength

(N/5×20cm)

Warp ≥850 ≥1000
Weft ≥1050 ≥1200
Tensile Elongation(%) Warp ≤30 ≤30
Weft ≤30 ≤30

Working

temperature (℃)

Continous ≤190 ≤190
Instant 230 230
Anti-acid Excellent Excellent
Anti-alkali Excellent Excellent
Anti-abrasion Excellent Excellent
The stability of water solution Excellent Excellent
Finishing treatment High temperature hot pressing,Singeing






Notices:



Exceptional Stability for a Wide Range of Temperature and Frequency Variations

Be suitable for the oxygen content below 15%

Chemical Resistance to Acids, Alkalis and Organic solvents

Containing moisture in the flue gas; Hydrolysis resistance

Very stable in finished felt form with stability standards at 2% shrink or stretch.

Favorable temperature resistance melting point 285℃, limited oxygen index 34~35;







Note:
1. special specification can be customized.
2. maximum width:2.3meters.
3. both filter cloth rolls and filter bags are available





Applications:



Coal - Fired Boilers bag houses Calciners / Catalysts

Municipal Solid Waste Boilers and Waste incinerator

Electric power plant Electrolysis and other Specialty membranes

Waste to energy Iron and non ferrous Metal Industry



Polyester Nylon PPS Filter Fabric 0Polyester Nylon PPS Filter Fabric 1Polyester Nylon PPS Filter Fabric 2



Hangzhou philis filter technology co.,ltd. has grown up to be one of leading manufacturer on dust filtration&spare parts in China.We have imported filter needle felt production line ASSELIN from France and we can produce very good quality non-woven products according customer's requirment.



Based on 8 needle felt production line ,our annual production ability can achieved 20,000 square meters per day . We can produce a large range of various filter fabric, such as polyester filter fabric, Acrylic filter fabric, Fiberglass filter fabric, PPS filter fabric, Aramid ,P84 ,PTFE ,woven filter fabric and so on.



The most important thing is that we introduced German high technology to develop the first filter bag production line in China. Which help most filter bag production factory save a lot of human lab our cost but promote the work effection . The advanced technology and simple operation way of automatic filter bag production line has won a lot of customer’s praise.
