Dust Collector SS Sintered Cloth Filter Cartridge Filter Elements

Dust Collector SS Sintered Cloth Filter Cartridge Filter Elements

  • Dust Collector SS Sintered Cloth Filter Cartridge Filter Elements
  • Dust Collector SS Sintered Cloth Filter Cartridge Filter Elements
  • Dust Collector SS Sintered Cloth Filter Cartridge Filter Elements
Dust Collector SS Sintered Cloth Filter Cartridge Filter Elements
Product Details:
Place of Origin: China
Brand Name: Philis
Certification: ISO
Model Number: liquid filter bag
Payment & Shipping Terms:
Minimum Order Quantity: 50pcs
Price: Negotiable
Packaging Details: standard export package
Delivery Time: within 10 days
Payment Terms: T/T
Supply Ability: 10000pcs per day
Contact Now
Detailed Product Description
Place Of Origin:: Zhejiang, China (Mainland) Type:: Filter Cylinder
Usage:: Filtering Material Of Bag:: SS304 & SS316
Filter Rating:: 98% Certification:: ISO 9001:2008
OEM Service:: Accept Warranty:: 12 Months
High Light:

pall filter bags

,

cement dust collector bags



Sintered Metal Filter Elements & Equipment Stainless Steel 316





Quick Detail:



The filter cartridge of high temperature dust removal is made of sintered several layers stainless steel metal mesh , it overcome the disadvantages of poor temperature tolerance, difficult to regenerate, low strength and poor wear resistance of traditional dust removal method, which put the air into cooling system first and then go into non-metal filter bag.





Main advantages:



1. Gas filters directly, easy operation;

2. Good permeability, uniform and stable precision, non-leakage.

3. Regenerate, easy installation, high efficiency and long service life.

1.Material: SUS304,316L

2.Rate:2-200um

3.Working temperature:-200----600°c

4.The shape could be machined on request.





Sintered Wire Mesh Laminate media



Main applications:



1.Distribution and cooling material in high temperature;

2.Material used for gas distribution and fluidization bed;

3.Material requiring high precision, stable performance in high temperature;

4.High pressure backwashed oil filter;





Advantages



1.High dirt holding capacity,high filtering accuracy,long working time

2.Corrosion resistance of acid and alkali,long working time at 600°C.

3.High porosity and excellent permeability,low pressure loss,high flow

4.Could be pleated in order to enlarge the filter area and welded

5.Cleanable,be used for many times(back wash)





Filter Cartridge



Brief Introduction:



Item Name Sintered SS Filter Cartridge
Porosity 40%(max)
Aperture 2.5-160μm
Filtration precision 0.2μm-80μm
Filtration Efficiency 98% filtration accuracy under:0.1 - 80um
Compressive Strength 3.0Mpa/cm2
Shape Tubular, Plate, Bar, Disc, Strip and so on.
Specification(mm) Thickness 0.5-20
Width Less than 250
Work environment Nitric acid, sulfuric acid, acetic acid, oxalic acid, phosphoric acid, 5% hydrochloric acid, molten sodium, hydrogen, nitrogen, hydrogen sulfide, acetylene, water vapor, hydrogen, gas, carbon dioxide gas environment































Packaging Details: Plastic bag+wooden box+certificates, as the clients' requirement
Delivery Detail: Normally ready goods and delivery deadline within 20-30 days
