Anti acid 5 micron polypropylene filter cloth for liquid filter bag

Anti acid 5 micron polypropylene filter cloth for liquid filter bag

    • Anti acid 5 micron polypropylene filter cloth for liquid filter bag
    • Anti acid 5 micron polypropylene filter cloth for liquid filter bag
    • Anti acid 5 micron polypropylene filter cloth for liquid filter bag
  • Anti acid 5 micron polypropylene filter cloth for liquid filter bag

    Product Details:

    Place of Origin: China
    Brand Name: Philis
    Certification: ISO
    Model Number: polypropylene filter cloth

    Payment & Shipping Terms:

    Minimum Order Quantity: 200meters
    Price: Negotiable
    Packaging Details: standard export package
    Delivery Time: within 10 days
    Payment Terms: T/T
    Supply Ability: 1000000sq.m per week
    Contact Now
    Detailed Product Description
    Usage:: Liquid Filter Type:: Filter Felt
    Sample:: Free Filter Precision:: 0.5-250microns
    Finishing Treatment:: Singeing, Calendering Weight:: 500gsm

    5 micron polypropylene filter cloth for liquid filter bag





    Quick Detail:



    High filtration efficiency ,long service life

    Good anti abrasion

    High temperature grade

    Anti acid ,anti alkali, chemical resistance

    High porosity ,good air permeability

    Good price quality

    Laminated compound,grads counterchange





    Description:



    Low temperature resistance ( 88-110 ℃)

    Excellent resistant to hydrolysis, acids and alkalies.

    Smooth surface, more defined pore size and good air permeability

    Lower fiber release, Lower density,High mechanical characteristics





    Specifications:



    Material Polypropylene / polypropylene scrim
    Weight(g/m2) 500 550 600 650
    Thickness(mm) 2.0 2.2 2.4 2.6
    Air permeability(m3/m3/min) 12.6 10.8 9.6 8.4
    Tensile Strength(N/5X20cm) Warp >960 >1150 >1350 >1500
    Weft >1060 >1400 >1650 >1800
    Tensile elongation(%) Warp <35 <35 <35 <35
    Weft <55 <55 <55 <55
    Working temperature(℃) Continues <90 <90 <90 <90
    Instant 110 110 110 110
    Anti-acid Excellent Excellent Excellent Excellent
    Anti-alkali Excellent Excellent Excellent Excellent
    Anti-abrasion Excellent Excellent Excellent Excellent
    Finishing treatment Singeing or high temperature press





    1.Style
    filter cloth
    2.Feature
    Aperture density uniform,Low resistance,large flow rate
    3.Material
    Nylon,Polyester,Stainless stell wire,Non woven
    4.Size
    OEM ,Customizing is welcome
    5.Color
    White,Black
    6.Specification
    7T-165T
    7.Noe
    80℃-150℃
    8.Is used to
    liquid filter,air filter,dust filter
    9.precision
    1um,5um,10um,20um 25um 75um 100um 150um
    10.Weight
    10kg





    Notices:



    Polypropylene is a relatively low temperature fiber with quite excellent chemical resistance which finds use in specialist applications such as the chemical industry.





    Applications:



    Galvanic industry and Chemical industryPrefiltering solvents and acids

    Prefilter to extend final filter lifeFinal filter for noncritical filtrations

    Liquid-solid sepration with strong acid and alkali conditions filter press

    Air filtration under 90℃



    Anti acid 5 micron polypropylene filter cloth for liquid filter bagAnti acid 5 micron polypropylene filter cloth for liquid filter bagAnti acid 5 micron polypropylene filter cloth for liquid filter bag




    Hangzhou philis filter technology co.,ltd. has grown up to be one of leading manufacturer on dust filtration&spare parts in China.We have imported filter needle felt production line ASSELIN from France and we can produce very good quality non-woven products according customer's requirment.



    Based on 8 needle felt production line ,our annual production ability can achieved 20,000 square meters per day . We can produce a large range of various filter fabric, such as polyester filter fabric, Acrylic filter fabric, Fiberglass filter fabric, PPS filter fabric, Nomex ,P84 ,PTFE ,woven filter fabric and so on.



    The most important thing is that we introduced German high technology to develop the first filter bag production line in China. Which help most filter bag production factory save a lot of human lab our cost but promote the work effection . The advanced technology and simple operation way of automatic filter bag production line has won a lot of customer’s praise.





    FAQ


    1. How to choose the right filter bags for your company?
    Cause every filter has its own characteristics and parameters, so when we choose filter material for filter bags, we have to know the following parameters:
    (1) Working temperature ( Continuous / Peak)
    (2)Measurement of filter bags
    (3) Gas’ chemical properties
    (4) Working pressure
    (5) Emission concentration

    2.How to assure the product quality?
    If you need , we can offer the sample for you, after your confirmation, we can produce the products according to your requirement.

    3.How many times can I clean and reuse a filter bags?
    Filter bags are designed for one time use. Attempting to clean a filter bags will stretch the material. Maybe some holes will get bigger and allow dust to get through. In our company, most of the fiber is imported, we use the best raw material to ensure the quality of filter cloth bags. Normally we can offer 2 years, 3years, 4years bags life time and even longer by your requirements.

    4.What shipments are available?
    Normally, we ship goods by sea,air or express. Special requirement can also be acceptable.

    5.Sample rule
    We offer you free samples as your requirement.If you are the first time to cooperate with us ,the postage should be paid by you. When you place the order ,we will return back to you in the next cooperation.
