Place of Origin: | China |
Brand Name: | Philis |
Certification: | ISO |
Model Number: | woven filter cloth |
Minimum Order Quantity: | 100meters |
---|---|
Price: | Negotiable |
Packaging Details: | standard export package |
Delivery Time: | within 10 days |
Payment Terms: | T/T |
Supply Ability: | 100000meters per week |
Certification: | CE ISO | Weight: | 9-300gsm Or According To Your Requires |
---|---|---|---|
Max Width: | 3.2m 2.4m 1.6m 1.8m (can Be Split) | Roll Length: | According To Customers' Request |
Max. Roll Diameter: | 1.1m | Working Temperature:: | Less 130℃ |
High Light: | water filter cloth,High Temperature Filter Media |
Polypropylene / PE / PA Monofilament / Long Thread Filter cloth , Anti Acid / Alkali Woven Filter Cloth
Quick Detail:
1. reliable mechanical resistance, high elasticity;
2. corrosion resistance
3. low density, light weight
4. wear resistance
5. used in kinds of filter
6. PP woven filter cloth for filter press machine
7. High tensile strength
8. Abrasion proof
Description:
We produce all kinds of PP filter cloth,
1. The weave:plain,twill,double twill
2. We have the type:840A,840B,750AB,750A,750B,108C,108B,etc
3. The PP filter cloth is widly used for chemical industry,pharmacy industry,smelting,stains industry and so on.
750B,721,663,1000,1000A......
Specifications:
Model | Breaking Strength | Density | Thickness | Weight | Air Permeability | Weave |
(N/5*20cm) | (root/10cm) | (mm) | (g/m2) | L/m2.s | ||
52l | 2608/2050 | 214.8/150.8 | 0.79 | 302.7 | 216.5 | Twill |
522 | 2104/1633 | 244/173 | 0.41 | 155 | 73.44 | Plain |
534 | 2501/1894 | 193.6/100.0 | 0.99 | 368.1 | 41.2 | Plain |
4212 | 2672/1342 | 236.4/123.2 | 1.34 | 389.4 | 85.6 | Twill |
700A | 3426.6/2819.4 | 204/106 | 0.7 | 350 | 117.9 | Plain |
700B | 4648.0/2866.6 | 188/114 | 0.59 | 280 | 254.2 | Twill |
700AB | 6865.4/416.7 | 378/235 | 1.15 | 580 | 82 | Twill+Plain |
750A(840A) | 4466/2905 | 168/131 | 0.85 | 330 | 42 | Plain |
750B(840B) | 5234/3489. | 256/141 | 0.99 | 420 | 76 | Twill |
750AB(840AB) | 6718/5421 | 333.8/204.4 | 1.36 | 489.9 | 24.5 | Plain |
840-1 | 5275/3948 | 252/146 | 0.9 | 440 | 45.5 | Twill |
840-2 | 5928/4086 | 283/142 | 1 | 490 | 40.7 | Twill |
840-3 | 6282/4858 | 311/134 | 1.1 | 520 | 27.2 | Twill |
858 | 4418/3618 | 251/124 | 0.88 | 380 | 240.7 | Twill |
4218 | 8568/5427 | 456/94 | 1.32 | 660 | 38.4 | Twill |
4422 | 2643/1514 | 181/94 | 1.18 | 480 | 17.86 | Twill |
1000A | 5585.7/4089.2 | 204/102 | 0.85 | 435 | 9.83 | Plain |
1000B | 6636/1481 | 204/110 | 0.79 | 430 | 21.49 | Twill |
1500-1 | 56283701 | 251118 | 1.42 | 725 | 29.38 | Twill |
108B | 8721/4642 | 503/133 | 1.1 | 600 | 13.6 | Double Twill |
108C | 8367/4797 | 504/177 | 1.03 | 600 | 22.96 | Satin |
Notices:
Meantimes we also supply PE(Polyester ),PA(Nylon) filter cloth to fit different application.
Any other question feel free to let us know.
Material
|
Item
|
Breaking Strength
(N/5*20cm)
|
Density
(Root/10cm)
|
Thickness
(mm)
|
Weight
(g/m2)
|
Air Permeability
(L/m2.s)
|
Weave
|
Polyester Filament
|
60-8(130)
|
1363/111.6
|
260.0/221.6
|
0.27
|
125.6
|
130.6
|
Plain
|
60-10(240)
|
2508/958.0
|
225.6/156.0
|
0.42
|
219.47
|
36.1
|
Plain
|
|
60-9(260)
|
2202/1776
|
205.6/160.8
|
0.47
|
257
|
32.4
|
Plain
|
|
60-7(621)
|
3026/2288
|
191.2/134.0
|
0.65
|
342.4
|
37.8
|
Plain
|
|
Polyester Staple Fiber
|
5926(120-7)
|
4498/4044
|
260/202
|
1.42
|
610
|
54
|
Twill
|
734(120-12)
|
2072/1633
|
232/166
|
0.62
|
245
|
480
|
Twill
|
|
745(120-13)
|
1936/730
|
232/196
|
0.48
|
210
|
125
|
Plain
|
|
747(120-14)
|
2026/1485
|
226/158
|
0.53
|
248
|
120
|
Plain
|
|
758(120-15)
|
2594/1909
|
194/134
|
0.73
|
330
|
100
|
Plain
|
|
3927(120-16)
|
4598/3154
|
156/106
|
0.9
|
524
|
18
|
Plain
|
|
728(120-17)
|
2753/1869
|
246/310
|
0.89
|
360
|
180
|
Twill
|
|
729
|
3180/2157
|
307/201
|
0.72
|
315
|
120
|
Plain
|
|
208
|
2788/1930
|
360/276
|
1.43
|
400
|
280
|
Twill
|
|
822
|
5760/3480
|
260/102
|
1.65
|
940
|
22
|
Twill
|
Applications:
Separation in solid and liquid to equip with filter press ,conveyor belts filtration Machine ,Filter Leaf ,Horizontal Rotating Pan Filter ,Vacuum filter ,in Chemical industry ,Fertilizer industry ,Sugar making ,food and beverage ,metallurgy ,Building ,Waste water dealing ,and so on .
The Polyester Filter Fabrics possess the properties of strong acid-rsistance, fair alkali-resistance, and operating temperature 130. They can be widely used in pharmaceuticals, non-ferrous metals metallurgical and chemical industrials, in the equipments of frame filter presses, centrifuge filters, vacuum filters, etc. The filtering precision can reach less than 5 micron.
Chemical Industries
Water Treatment
Dyestuff&Pigments
Metallurgy Industries
Pharmacy
Architecture
Cement Plants
Sample lead time:1~7 days, Free sample,
We do quotation within 2 days and welcome your any inquiry at any time.
A: Welcome any OEM requirements.
B: We offer instruction for customers to the usage of our product.
C: We offer goods return and goods exchange for reasonable situation.
D: We've got experts ready to solve some professional questions.
E: Professional shipping service if necessary.
F: We can produce products according to customer's request.
Hangzhou philis filter technology co.,ltd. has grown up to be one of leading manufacturer on dust filtration&spare parts in China.We have imported filter needle felt production line ASSELIN from France and we can produce very good quality non-woven products according customer's requirment.
Based on 8 needle felt production line ,our annual production ability can achieved 20,000 square meters per day . We can produce a large range of various filter fabric, such as polyester filter fabric, Acrylic filter fabric, Fiberglass filter fabric, PPS filter fabric, Nomex ,P84 ,PTFE ,woven filter fabric and so on.
The most important thing is that we introduced German high technology to develop the first filter bag production line in China. Which help most filter bag production factory save a lot of human lab our cost but promote the work effection . The advanced technology and simple operation way of automatic filter bag production line has won a lot of customer’s praise.
