White PTFE Coated Alkali / Non-Alkali Filter Fabric Roll 330 - 900gsm woven roving plain cloth

White PTFE Coated Alkali / Non-Alkali Filter Fabric Roll 330 - 900gsm woven roving plain cloth

  • White PTFE Coated Alkali / Non-Alkali Filter Fabric Roll 330 - 900gsm woven roving plain cloth
  • White PTFE Coated Alkali / Non-Alkali Filter Fabric Roll 330 - 900gsm woven roving plain cloth
White PTFE Coated Alkali / Non-Alkali Filter Fabric Roll 330 - 900gsm woven roving plain cloth
Product Details:
Place of Origin: China
Brand Name: Philis
Certification: ISO
Model Number: glassfiber filter cloth
Payment & Shipping Terms:
Minimum Order Quantity: 100m
Price: Negotiable
Packaging Details: standard export package
Delivery Time: within 10 days
Payment Terms: T/T
Supply Ability: 10000m per week
Contact Now
Detailed Product Description
Width:: 1m, 1.25m, 2m Color:: White Or Black
Length:: 100m,150m,200m, Etc Sample:: Free
Material: Fiberglass Weave Type:: Plain, Twill, Double Twill
High Light:

micron filter cloth

,

filter fabric roll

White PTFE Coated Alkali / Non-Alkali Filter Fabric Roll 330 - 900gsm





Quick Detail:



High filtration efficiency ,long service life

Good anti-abrasion

High temperature grade

Anti - acid ,anti - alkali, chemical resistance

High porosity ,good air permeability

Good price quality

Laminated compound,grads counterchange





Description:



Glass fiber filter media, including fiberglass needle felt and woven fiberglass filter cloth,because of it's high temperature resistant, anti-condensation,dimensions stability, dust stripping is good, and high filtration efficiency is widely used in metallurgy, cement, power generation, carbon black, coal-fired boilers, chemical industry and waste incineration industries.





Specifications:



Glass fiber filter felt Technical parameters



Type ZLN-BX-01(Single side web) ZLN-BX-02(Double side web)
Weight(g/m2) 800 900
Air permeability(m2m2/min) 9~18 8~15
Tensile strength (N/5×20cm) Warp >1850 >1800
Weft >1600 >1800
Tensile Elongation (%) Warp <10 <10
Weft <10 <10
Broken strength(Mpa/min) 3.1 3.0
Working temperature(°C) 260~300 260~300
Anti-acid Excellent Excellent
Anti-alkali Medial Medial
Anti-abrasion Bad Bad
The stability of water solution Medial Medial
Finishing treatment treatment treatment





Glass Fiber Finished filter cloth specification:




Item No.
LOI (%) Weave Weight (g/m2) Mullen burst (kpa) Tensile strength (N/2.5cm) Air permeability(cm3/cm2/s·127pa) Finished Running temperature
(°C)
warp weft
FA301 > 10 double twill 780-850 > 6200 > 2400 > 2000 15-30 PTFE <260
FI301 > 10 double twill 780-850 > 6200 > 2400 > 2000 15-30 PI <260
FB302 > 2 1/3 twill 450-500 > 4500 > 2000 > 1200 20-36 PGS <260
FC302 > 5 1/3 twill 340-380 > 4500 > 2000 > 1200 20-36 AR <260
FA303 >10 1/3 twill 320-360 > 3500 > 1400 > 800 22-35 PTFE <260
FC303 > 5 1/3 twill 900-950 > 3400 > 1200 > 700 22-35 AR <260
FD502 > 7 satin 900-950 > 8000 > 3000 > 2400 15-25 PD <400
FA404 > 10 double twill 800-850 > 5000 > 2600 > 2200 15-30 PTFE <260
FE201 >1.7 satin 550-600 > 5500 > 2200 > 2000 20-35 PG <260
FE203 > 1.7 1/3 twill 550-600 > 5500 > 2200 > 2000 20-35 PG

<260






Notices:



glass fiber needle felt is one kind of high temperature resistant filter material with reasonable structure and excellent performance,it could be high temperature resistant,anti-abrasion,stable size,little elongation shrinkage ratio,high intension,also ultimate fiber of felt layer fiber,three dimensional micro pore structure,high porosity,small filter resistance to gas,it has higher speed and efficiency,Comparing with other high temperature resistant chemical fiber felt,it has the advantage of lower price,high temperature resistant,but due to high resistance, filtering efficiency is lower





Applications:



Chemical plant Cement plant

Steel iron plant Melting plant

Carbon black plant Electricity Industry



White PTFE Coated Alkali / Non-Alkali Filter Fabric Roll 330 - 900gsm woven roving plain cloth 0

White PTFE Coated Alkali / Non-Alkali Filter Fabric Roll 330 - 900gsm woven roving plain cloth 1White PTFE Coated Alkali / Non-Alkali Filter Fabric Roll 330 - 900gsm woven roving plain cloth 2





Hangzhou philis filter technology co.,ltd. has grown up to be one of leading manufacturer on dust filtration&spare parts in China.We have imported filter needle felt production line ASSELIN from France and we can produce very good quality non-woven products according customer's requirment.



Based on 8 needle felt production line ,our annual production ability can achieved 20,000 square meters per day . We can produce a large range of various filter fabric, such as polyester filter fabric, Acrylic filter fabric, Fiberglass filter fabric, PPS filter fabric, Nomex ,P84 ,PTFE ,woven filter fabric and so on.



The most important thing is that we introduced German high technology to develop the first filter bag production line in China. Which help most filter bag production factory save a lot of human lab our cost but promote the work effection . The advanced technology and simple operation way of automatic filter bag production line has won a lot of customer’s praise.
