Nonwoven Industrial Filter Bag , PPS P84 Filter Fabric Liquid Filter Bag

Nonwoven Industrial Filter Bag , PPS P84 Filter Fabric Liquid Filter Bag

  • Nonwoven Industrial Filter Bag , PPS P84 Filter Fabric Liquid Filter Bag
  • Nonwoven Industrial Filter Bag , PPS P84 Filter Fabric Liquid Filter Bag
  • Nonwoven Industrial Filter Bag , PPS P84 Filter Fabric Liquid Filter Bag
Nonwoven Industrial Filter Bag , PPS P84 Filter Fabric Liquid Filter Bag
Product Details:
Place of Origin: China
Brand Name: Philis
Certification: ISO
Model Number: industrial filter bag
Payment & Shipping Terms:
Minimum Order Quantity: 100pcs
Price: Negotiable
Packaging Details: standard export package
Delivery Time: within 10 days
Payment Terms: T/T
Supply Ability: 3000pcs per day
Contact Now
Detailed Product Description
Certificate:: ISO9001-2008 Material Of Bag:: Non-woven
Finish:: Singeing Calendering Heat Seating Place Of Origin:: Zhejiang, China (Mainland)
Type:: Pocket Filter Package:: Carton With Plastic Bag Inside
High Light:

industrial dust collector bags

,

pall filter bags

Nonwoven Industrial Filter Bag , PPS P84 Filter Fabric Liquid Filter Bag





Quick Detail:



1. High quailty
2. Competitive price
3. ISO certification
4. Strict quality control





General bag sizes:



Item Dia(inch) length(inch) mm
1# 7″ 17″ 180X420
2# 7″ 32″ 180X810
3# 4″ 9″ 102X230
4# 4" 15″ 102X410
5# 6" 22″ 152x559



Main Parameters of 2017 promotion wholesale Industrial water PP liquid filter bag:



Material PE,PP,NMO
Bag top ring Plastic ring , Stainless steel ring
Relative filtration pore size 0.5, 1,5, 10, 25, 50, 100, 200 ,300µm
Type various specifications
Airtight method: Hot Melt, reverse sewing
Effective filtration area various specifications
Others

special requirement of diameter and collar extension can be customized







Main Parameters:
Material PE, PP, Acrylic,PPS,Milter, P84,Metamax. Glass fibre & FMS
Temperature (130° C ) or high temperature (300° C).
Technics Basic cloth & PTFE Membrane & water and oil repellent & Antistatic.
Thickness: Around 1.6mm & according to customers requirement
Air permeability: (30-400)L/M2/S at 200Pa according to different fabric
Dimension: Normal with width in0.45m To 2.3m, length in 100m/roll or 50m/roll dominated by customers.
Strength: up to(550N x 1800N) /(5x20cm) according to different fabric
Color: Snow White, Yellow, Grey, black and so on
Package : In inner polybag & outter woven polybag with paper tube inside the axis Carton with bags in any dimension.





Nonwoven dust filter bag Continuous Temperature Peak Temperature Description Resistance to Acids Resistance to Alkalis Resistance to Oxidation PH Value
Polypropylene 90°C 100°C PP excellent excellent restricted 1-14
Polyacrylyitrile Homopolymer 125°C 140°C DT good good good 3-11
Polyester 130°C 150°C PE restricted moderate good 4-12
Polyphenylensulfide 190°C 200°C PPS excellent excellent moderate 1-14
Nomex 204°C 250°C Nomex good excellent good 3-14
Polymide 260°C 300°C P84 good moderate good 3-13
Polytertrafluoroethylene 250°C 280°C PTFE excellent excellent excellent 1-14
Glass fiber 260°C 300°C BQ good good good 3-11



Main product: Dust filtration,liquid filter filtration and related machines

1. Dust filtration-----filter bag


Polyester filter bag,polyester antistatic filter bag,polyester filter bag blending,polyester filter bag with membrane,polyester filter bag water and oil repellent,polyester filter bagspecial type,pp filter bag,aramid filter bag pps filter bag acrylic filter bag, p84 filter bag, ptfe filter bag,ptfe mix p84filter bag,HST filter bag,fiberglass filter bag,PTFE mix pps filter bag,Basalt filter bag and so on.



2. Liquid filtration filter bag


Polyester filter bag, PE filter bag, Micro filter bag,5 micro filter bag,10 micro filter bags,PP filter bag,nylon filter bag,ptfe filter bag,stainsteel filter bag and so on.


3. Machines for making dust filter bags


Automatic filter bag tube line,Semi-Automatic filter bag tube line,Tripe-needle filter bag sewing machine,double need sewing machine, long arm sewing machine,overlock sewing machine,slitting machine,filter bag bottom punching machine,package machines,needle punch line and so on.



Usagae/Occasion

Filter bag can be used for industrial filtration,product filtration,solid/liquid separation, like:
- Asphalt mixing plants
- Biomass power stations
- Chemical and pharmaceutical industry
- High temperature dedusting
- Coal-fired power stations
- Food industry
- Non-ferrous metal and steel production
- Cement, gypsum and lime industry
- Thermal waste treatment



Nonwoven Industrial Filter Bag , PPS P84 Filter Fabric Liquid Filter Bag 0Nonwoven Industrial Filter Bag , PPS P84 Filter Fabric Liquid Filter Bag 1Nonwoven Industrial Filter Bag , PPS P84 Filter Fabric Liquid Filter Bag 2





FAQ



1. Q: Are you manufacturer ?

A:Yes, we are the manufacturer with continuous and improved R & D, production, sales and service supply.



2.Q: How to get a quotation ?
A: In order to send you our best price, please kindly inform us detailed product parameters.



3.Q: Could you provide free sample of filter bag ?
A: Yes, we could provide free sample if the value not big, but the courier charge will be on your side. And we'll send back the courier charge if you place an order to a certain amount.



4.Q: What’s your payment terms ?
A: Mainly accept Paypal, West Union and T/T, L/C is also available if order amount big. For Samples: 100% in advance via Paypal,West Union or T/T. Formal order: 30%T/T in advance and balance against the Copy of B/L. Other payment terms can be further discussed.



5.Q: Can I get your products with our logo and design ?
A: Most of products are OEM or ODM with your logo and customized products will be extra costed.



6.Q: What is your delivery time ?

A:In normal condition, the delivery time is 7-15days for regular products if we have enough raw material. For big order quantity, we'll firstly try our best to meet your demand offer you the shortest delivery time
