Polyester / Polypropylene Micron Filter Bag , industrial air filter bag

Polyester / Polypropylene Micron Filter Bag , industrial air filter bag

  • Polyester / Polypropylene Micron Filter Bag ,  industrial air filter bag
  • Polyester / Polypropylene Micron Filter Bag ,  industrial air filter bag
  • Polyester / Polypropylene Micron Filter Bag ,  industrial air filter bag
Polyester / Polypropylene Micron Filter Bag ,  industrial air filter bag
Product Details:
Place of Origin: China
Brand Name: Philis
Certification: ISO
Model Number: dust filter bag
Payment & Shipping Terms:
Minimum Order Quantity: 100pcs
Price: Negotiable
Packaging Details: standard export package
Delivery Time: within 10 days
Payment Terms: T/T
Supply Ability: 3000pcs per day
Contact Now
Detailed Product Description
Type:: Pocket Filter Material Of Bag:: Non-woven
Package:: Carton With Plastic Bag Inside Micron Rating:: 0.5~1000micron
Usage:: Dust Filter Certificate:: ISO9001
High Light:

industrial dust collector bags

,

cement dust collector bags

Polyester / Polypropylene Micron Filter Bag ,  industrial air filter bag





Quick Detail:



Material : PP or PE,polyester, polypropylene

Micron rating : 0.5um ~800um

Good anti-abrasion

High temperature grade

Anti-acid ,anti-alkali, chemical resistance

High porosity ,good air permeability

Laminated compound,grads counterchange





Description:



Low temperature resistance ( 88-110 ℃)

Excellent resistant to hydrolysis, acids and alkalies.

Smooth surface, more defined pore size and good air permeability

Lower fiber release, Lower density,High mechanical characteristics





Specifications:



#1-----(7"x16") -----¢180*410mm



#2-----(7" x 32") -----¢180*810mm



#3-----(4"x 8 1/4") -----¢102*210mm



#4-----(4"x 14") -----¢102*356mm



Material PE,PP,NMO,PTFE
Cuff PP Lock, Stainless steel
Relative filtration pore size 0.5, 1,5, 10, 25, 50, 100, 200 µm
Type various specifications
Airtight method: Hot Melt, reverse sewing
Effective filtration area various specifications
Others special requirement of diameter and collar extension can be customized





Model No.
Material
Weight
Thickness
Breaking strength
Using temperature


g/m2
mm
vertically
horizontally
polyester needle felt
polyester fibre
400-650
1.7-2.05
900-1140
1100-2000
≤130
polypropylene needle felt
polypropylene fibre
400-650
1.8-2.6
950-1500
900-1400
≤130
anti-static needle felt

polyester fibre

electric fibre

400-600
1.6-2.4
1000-1400
800-1200
≤130
water and oil replelient needle felt

polyester fibre

coating

400-600
1.4-1.9
900-1140
1100-2000
≤130
FMS needle felt
high temperature resisting fibre
>800
1.8
1600
1400
≤260
metamax needle felt
metamax fibre
500
2.3
1000
900
≤204
PPS needle felt
poly-p-propylence
500-550
2.0
≥800
≥1200
≤170
PTFE coated needle felt

polyester fibre or metamax needle felt

PTFE coating

400-650
1.4-2.3


≤260
P84
P84 fiber
500



≤260
fiberglass
glass fiber
900



240



Advantages

1. dust collector filter bag are carefully fabricated and sized to ensure ease of installation and
change-out.
2. dust collector filter bags are designed to be mounted and gasketed firmly into place with a snap band, corded cuff, or clamp to ensure dust tight seal.
3. Various coatings and finishes can be applied to either side of the dust collector bag to enhance cleaning and efficiencies, as well as prolonging service life.
4. Groundwire, anti-collapse rings and other options can be easily incorporated into bag construction.





Notices:



1. Materials avaliable: polyester, polypropylene

2. construction: welded or sewn

3. collar type: steel ring or plastic ring

4. finishing treatment: singed, calendared, heat set

5. Size available: standard and custom size.





Applications:



1. Paints & lacquer industry
2. Wastewater treatment
3. Pharmaceutical industry
4. Food industry
5. Chemical industry
6. Beer, wine & spirit industry
7. Adhesive.



Polyester / Polypropylene Micron Filter Bag ,  industrial air filter bag 0Polyester / Polypropylene Micron Filter Bag ,  industrial air filter bag 1Polyester / Polypropylene Micron Filter Bag ,  industrial air filter bag 2



Hangzhou philis filter technology co.,ltd. has grown up to be one of leading manufacturer on dust filtration&spare parts in China.We have imported filter needle felt production line ASSELIN from France and we can produce very good quality non-woven products according customer's requirment.



Based on 8 needle felt production line ,our annual production ability can achieved 20,000 square meters per day . We can produce a large range of various filter fabric, such as polyester filter fabric, Acrylic filter fabric, Fiberglass filter fabric, PPS filter fabric, Nomex ,P84 ,PTFE ,woven filter fabric and so on.



The most important thing is that we introduced German high technology to develop the first filter bag production line in China. Which help most filter bag production factory save a lot of human lab our cost but promote the work effection . The advanced technology and simple operation way of automatic filter bag production line has won a lot of customer’s praise.
